Diluents & Modifiers Portfolio

Cardanol-based epoxy resins, diluents, and modifiers offer formulators versatile formulation tools to enhance coating and adhesive performance. Reactive and non-reactive diluents reduce viscosity for low and zero VOC formulations while improving flexibility, corrosion resistance, and water resistance. Difunctional epoxy resins and polyfunctional epoxy novolacs further enhance system flexibility and toughness without greatly compromising mechanical properties.

Reactive Diluents

Cardolite Ultra LITE 513 molecule

Monofunctional Epoxy Diluent Series

The Cardolite family of monofunctional epoxy diluents deliver efficient viscosity reduction and consistent performance. NC-513 is the standard grade, while Ultra LITE 513 offers higher purity, lower viscosity, and very light color, making it an excellent choice over traditional monofunctional glycidyl ether diluents.

Key Benefits:

  • High dilution efficiency
  • High flexibility
  • High water and chemical resistance
  • Good toughness and thermal shock resistance
  • Good epoxy resin and curing agent compatibility
  • Alternative to other monofunctional glycidyl ethers
  • 100% bio-based material
icon
Epoxy Reactive Diluent

NC-513


Cardolite NC-513 is a low viscosity, monofunctional epoxy reactive diluent designed for coatings, adhesives, and other epoxy applications.

– Adds flexibility and lowers viscosity while maintaining performance
– Excellent chemical and water resistance
– Increased thermal shock resistance

View TDS/MSDS

icon
Epoxy Reactive Diluent

Ultra LITE 513


Cardolite Ultra LITE 513 is a very light color, low viscosity, monofunctional epoxy reactive diluent designed for coatings, adhesives, and other epoxy applications.

– Adds flexibility and lowers viscosity while maintaining performance
– Excellent chemical and water resistance
– Increased thermal shock resistance

View TDS/MSDS

Epoxy Modifiers

LITE 513DF – High Strength Diluent

Cardolite LITE 513DF is a high bio-content epoxy diluent and modifier designed to balance sustainability with performance. Its lower epoxy equivalent weight and very low viscosity make it highly efficient in epoxy formulations, while its cashew-derived backbone brings added durability and environmental value. This grade has demonstrated reliable protection and versatility, offering formulators an excellent alternative to conventional petroleum-based diluents.

Key Benefits

  • Excellent dilution power
  • Good hardness development at room and low temperature
  • Excellent mechanical properties
  • Excellent water and chemical resistance
  • Good dielectric properties
  • High bio-content alternative to petro-based mono and difunctional diluents

Epoxy Resins

Cardolite LITE 514HP molecule

NC-514, NC-514S, and LITE 514HP are CNSL-based difunctional glycidyl ether epoxy resins designed to enhance coating performance.

Key Benefits

  • Alternative to Bisphenol A technology
  • High bio-content specialty epoxy resin
  • Good flexibility and toughness
  • Hydrophobic, offers improved water resistance
  • Suitable for 1k and 2k epoxy systems

Novolac Epoxy Resins

Cardoltie LITE 547LV molecule

NC-547 and LITE 547LV are epoxy novolac resins derived from cardanol that improve the mechanical performance of standard epoxy resins.

Key Benefits

  • Excellent flexibility at low temperature
  • Excellent thermal shock resistance
  • Excellent water resistance
  • Good chemical resistance
  • Good compatibility with Bis-A based epoxy (LITE 547LV)
  • BPA free, high bio-content
  • Low viscosity, solvent-free novolac

Recommended Products

icon
Epoxy Reactive Diluent

LITE 513DF


Cardolite LITE 513DF is a light color, epoxy reactive diluent and modifier based on cashew nutshell liquid technology.

– Low viscosity, low color di-functional diluent
– Balanced mechanical properties
– Best option to leverage dilution and performance

View TDS/MSDS

icon
Flexible Epoxy Resin

LITE 514HP


Cardolite LITE 514HP is a flexible di-functional glycidyl ether epoxy resin based on cashew nutshell liquid technology.

– Mid viscosity, light color epoxide
– High mechanical strengths
– Best option for water resistance and hydrolytic stability

View TDS/MSDS

icon
Epoxy Novolac Resin

LITE 547LV


Cardolite LITE 547LV is a low viscosity epoxy novolac resin derived from renewable cashew nutshell liquid technology.

– Lower viscosity, light color novolac epoxide
– Excellent flexibility
– Best option to improve adhesion while maintaining high Tg

View TDS/MSDS

Non-Reactive Diluents

NX-202X Series

Cardanol chemical structure

NX-202x products are low-viscosity, multipurpose resin modifiers designed to enhance performance in various chemistries.

Key Benefits

  • Excellent dilution efficiency
  • Excellent water resistance
  • Good epoxy-amine acceleration effect
  • Good flexibility and toughness
  • Label-friendly alternative to nonylphenol

2020 Series

Chemical structure of Cardolite Ultra LITE 2020

LITE 2020 and Ultra LITE 2020 resins are suitable for formulating environmentally friendly high-solids or solvent-free epoxy systems.

Key Benefits

  • Good dilution efficiency
  • Good chemical and water resistance
  • Good flexibility
  • Improves intercoat adhesion with polyurethane
  • Extends pot life of resin system

Non-Reactive Diluents Typical Properties

ProductTypeColor (Gardner)Viscosity (cPs)Documents
NX-2024Non-reactive resin modifier4 - 945 - 60TDS/MSDS
NX-2025Non-reactive resin modifier≤ 5≤ 60TDS/MSDS
NX-2026Non-reactive resin modifier≤ 2≤ 60TDS/MSDS
Ultra LITE 2023Non-reactive resin modifier140 - 100TDS/MSDS
LITE 2020Non-reactive resin modifier≤ 1430 - 115TDS/MSDS
Ultra LITE 2020Non-reactive resin modifier≤ 2≤ 115TDS/MSDS
LITE 2100Hydrocarbon resin modifier≤ 4450 - 750TDS/MSDS
LITE 2100RHydrocarbon resin modifier≤ 4500 - 1,000TDS/MSDS
LITE 2105Styrene-free hydrocarbon resin modifier2750 - 1,050TDS/MSDS
LITE 2105LVStyrene-free hydrocarbon resin modifier2135 - 175TDS/MSDS
